Aruba 2920-48G-POE+ 740W Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
Expert team support
Bulk InquiryWe accept POs from fortune 1000 companies, government agencies, defense, schools and hospitals.
Description
Specification
Media
Reviews
Description
Product Features:
- Managed L3 Web-based management
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 48
- 10G support 10BASE-T, 100BASE-TX, 1000BASE-T
- MAC address table: 16000 entries Switching capacity: 176 Gbit/s
- Access Control List (ACL)
- 1U Rack mounting Stackable
- Power over Ethernet (PoE)
Aruba 2920-48G-POE+ 740W Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
HPE J9836A Aruba 2920-48g-poe+ 740w Switch Switch 48 Ports Managed Rack-mountable.
Aruba 2920-48G-POE+ 740W. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Switching optical modules type: 40 Gigabit Ethernet. Full duplex. MAC address table: 16000 entries, Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Specification
Management features
Switch type
Managed
Switch layer
L3
Quality of Service (QoS) support
Web-based management
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Network
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
10G support
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex
IP routing
Flow control support
Link aggregation
Auto MDI/MDI-X
Spanning tree protocol
Auto-sensing
Optical fiber
Switching optical modules type
40 Gigabit Ethernet
Data transmission
Switching capacity
176 Gbit/s
Throughput
130.9 Mpps
MAC address table
16000 entries
Latency (10-100 Mbps)
9 µs
Latency (1 Gbps)
3.2 µs
Latency (10 Gbps)
3.2 µs
Jumbo frames support
Packet buffer memory
11.25 MB
Security
DHCP features
DHCP server
Access Control List (ACL)
IGMP snooping
SSH/SSL support
Multicast features
Multicast support
Design
Rack mounting
Stackable
Form factor
1U
Product colour
Grey
Performance
Virtual stacking (units)
4
Built-in processor
Processor frequency
625 MHz
Memory type
SDRAM
Internal memory
512 MB
Flash memory
1024 MB
Power
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (typical)
881 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget
740 W
Operational conditions
Operating temperature (T-T)
0 - 55 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
15 - 95%
Storage relative humidity (H-H)
15 - 95%
Heat dissipation
482 BTU/h
Weight & dimensions
Width
442.5 mm
Depth
336 mm
Height
43.9 mm
Weight
5.83 kg
