Name: Aruba CX 6200F 24G 4SFP Managed L3 Gigabit Ethernet (10/100/1000) 1U
Brand: Aruba
SKU: S0M81A#ABA
Price: 4466 USD
Availability: InStock
Rating: 4.303329380456793

Description

Specification

Reviews

Description

Product Features:

Managed L3
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 24 Console port: RJ-45/USB Type-C
MAC address table: 32768 entries Switching capacity: 128 Gbit/s
Access Control List (ACL)
1U Rack mounting Stackable
AC Power supply included

Aruba CX 6200F 24G 4SFP Managed L3 Gigabit Ethernet (10/100/1000) 1U

HPE S0M81A#ABA Aruba Networking Cx 6200 Switch Series - 1u - Wired - 1gbps - Networking / Ports Qty: 31 - Gigabit Ethernet - Arm Cortex A72 - 8gb Ram - 16gb Flash Memory - 100v-120v/200v-240v Switch.

Aruba CX 6200F 24G 4SFP. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45/USB Type-C. MAC address table: 32768 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE.... Rack mounting, Form factor: 1U

Specification

Management features

Switch type

Managed

Switch layer

Quality of Service (QoS) support

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

SFP module slots quantity

Console port

RJ-45/USB Type-C

Network

Networking standards

IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z

Port mirroring

Flow control support

Link aggregation

Auto MDI/MDI-X

VLAN support

Optical fiber

Transmission distance (max)

10 km

Data transmission

Switching capacity

128 Gbit/s

Throughput

95.2 Mpps

MAC address table

32768 entries

Latency (1 Gbps)

2.28 µs

Latency (10 Gbps)

1.46 µs

Jumbo frames support

Packet buffer memory

8 MB

Security

Access Control List (ACL)

IGMP snooping

Authentication

MAC-based authentication, Web-based authentication

Authentication type

RADIUS, TACACS+

Multicast features

Multicast support

Protocols

Routing protocols

OSPF, OSPFv2, OSPFv3, RIP-2, RIPng

IPv4 & IPv6 features

IPv4/IPv6 access-control list (ACL)

Design

Rack mounting

Stackable

Form factor

Performance

Physical stacking (units)

Built-in processor

Processor model

ARM Cortex-A72

Processor frequency

1800 MHz

Memory type

SDRAM / Flash

Internal memory

8192 MB

Flash memory

16384 MB

Power

Power source

Power supply included

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Power consumption (typical)

59 W

Power over Ethernet (PoE)

Operational conditions

Operating temperature (T-T)

0 - 45 °C

Storage temperature (T-T)

-40 - 70 °C

Operating relative humidity (H-H)

5 - 95%

Storage relative humidity (H-H)

5 - 95%

Operating altitude

0 - 3048 m

Weight & dimensions

Width

442 mm

Depth

327 mm

Height

43.9 mm

Weight

5.1 kg
