Aruba CX 6300F Managed L3 Gigabit Ethernet (10/100/1000) Black
Expert team support
Bulk InquiryWe accept POs from fortune 1000 companies, government agencies, defense, schools and hospitals.
Description
Specification
Media
Reviews
Description
Product Features:
- Stackable Layer 3 switches with BGP, EVPN, VXLAN, VRF, and OSPF with robust security and QoS
- High performance 880 Gbps system switching capacity, 660 MPPS of system throughput and up to 200 Gbps stacking bandwidth
- Compact 1U switches with full density HPE Smart Rate (1/2.5/5GbE) multi-gigabit, 60W PoE and SFP+ models
- Built-in high speed 10GbE/25GbE/50GbE uplinks
- Intelligent monitoring, visibility, and remediation with Aruba Network Analytics Engine
- One touch deployment with the Aruba CX Mobile App
- Aruba NetEdit support for automated configuration and verification
- Aruba Dynamic Segmentation enables secure and simple access for users and IoT
- Managed L3
- Quality of Service (QoS) support Configuring Location Settings (CLI)
- Basic switching RJ-45 Ethernet ports quantity: 24 Console port: USB
- 10G support
- Switching capacity: 448 Gbit/s
- Access Control List (ACL)
- Rack mounting Stackable
- Power supply included
Aruba CX 6300F Managed L3 Gigabit Ethernet (10/100/1000) Black
HPE JL668A Aruba 6300f 24-port 1gbe And 4-port Sfp56 Switch ( Internal (fixed) Power Supply (200w).
Aruba CX 6300F. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, USB 2.0 ports quantity: 1, Console port: USB. Switching capacity: 448 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE.... Rack mounting
Specification
Management features
Switch type
Managed
Switch layer
L3
Quality of Service (QoS) support
Configuring Location Settings (CLI)
System event log
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
4
Console port
USB
USB 2.0 ports quantity
1
Network
Networking standards
IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3bt
10G support
Port mirroring
IP routing
Policy-based routing
Link aggregation
Auto MDI/MDI-X
Spanning tree protocol
VLAN support
Optical fiber
Transmission distance (max)
10 km
Data transmission
Switching capacity
448 Gbit/s
Throughput
334 Mpps
Latency (1 Gbps)
2.28 µs
Latency (10 Gbps)
1.46 µs
Number of queues
8
Packet buffer memory
8 MB
Security
DHCP features
DHCP relay, DHCP server
Access Control List (ACL)
IGMP entries
8000
SSH/SSL support
Multicast features
Multicast support
IPv4 multicast entries
8000
IPv6 multicast entries
8000
Number of multicast groups filtered
8000
Protocols
Routing protocols
OSPF, OSPFv3
Design
Rack mounting
Stackable
Product colour
Black
Airflow direction
Front-to-back airflow
Certification
EN 60950-1:2006; +A11:2009 +A1:2010; +A12:2011 + A2:2013
UL 60950-1 2nd Ed
CAN/CSA-C22.2; No. 60950-1-07
IEC 60950-1:2005
EN 55022:2010, A; EN 55032:2012, A; EN 55024:2010; EN 61000-3-2:2014; EN 61000-3-3:2013
FCC 15 A
ICES-003 A
VCCI A; CISPR 22 A; CISPR 32 A; CISPR 24:2010
Performance
Physical stacking (units)
10
Built-in processor
Processor model
ARM Cortex-A72
Processor frequency
1800 MHz
Internal memory
8192 MB
Flash memory
32000 MB
Noise level
31.6 dB
Power
Power supply included
Number of power supply units
1
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Input current
2.5/1.4 A
Power consumption (max)
63 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
15 - 95%
Storage relative humidity (H-H)
15 - 90%
Operating altitude
0 - 3040 m
Non-operating altitude
0 - 4600 m
Weight & dimensions
Width
442 mm
Depth
327 mm
Height
43.9 mm
Weight
4.36 kg
Packaging data
Rack mount kit
Logistics data
Harmonized System (HS) code
85176990
