Cisco Catalyst C8500-12X4QC network switch Managed L2/L3 None 1U Grey
Expert team support
Bulk InquiryWe accept POs from fortune 1000 companies, government agencies, defense, schools and hospitals.
Description
Specification
Media
Reviews
Description
Product Features:
- Managed L2/L3 Web-based management
- Quality of Service (QoS) support
- Console port: RJ-45
- 10G support
- 4000 Access Control List (ACL)
- 1U Rack mounting
Cisco Catalyst C8500-12X4QC network switch Managed L2/L3 None 1U Grey
CISCO C8500-12X4QC Catalyst 8500-12x4qc Edge Platform - Switch - 12 X 1 Gigabit / 10 Gigabit Sfp+ + 2 X 40 Gigabit Qsfp+ + 2 X 40/100 Gigabit Qsfp28 - Rack-mountable.
Cisco Catalyst C8500-12X4QC. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: None, Console port: RJ-45. Networking standards: IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3ah. DC input voltage: 40 - 72 V. Rack mounting, Form factor: 1U
Specification
Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Web-based management
Ports & interfaces
Basic switching RJ-45 Ethernet ports type
None
SFP+ module slots quantity
12
QSFP+ module slots quantity
2
Console port
RJ-45
QSFP28 ports quantity
2
Network
Networking standards
IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3ah
10G support
Port mirroring
IP routing
Data transmission
Throughput
68000 Mpps
Throughput
197 Gbit/s
Security
DHCP features
DHCP client, DHCP relay, DHCP server
Access Control List (ACL)
Access Control List (ACL) rules
4000
Access Control List (ACL) IPv4 entries
380000
Security algorithms
128-bit AES, 256-bit AES, IPSec, MD5, RSA, SHA-256, SHA-384, SHA-512
Multicast features
Multicast support
Design
Rack mounting
Form factor
1U
Product colour
Grey
LED indicators
Electromagnetic compatibility
47 CFR Part 15 Class A, ICES 003 Class A, AS/NZS CISPR 32 Class A, CISPR 22/CISPR 32 Class A, EN55022/EN55032 Class A, VCCI Class A, CNS-13438 Class A, KN32 Class A, IEC/EN 61000-3-2, IEC/EN 61000-3-3, EC/EN-61000-4-2, IEC/EN-61000-4-3, IEC/EN-61000-4-4, IEC/EN-61000-4-5, IEC/EN-61000-4-6, IEC/EN-61000-4-1, KN35, EN300 386, EN55022, EN55032, EN55024, EN55035, EN50082-1/EN-61000-6-1
Certification
UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943
Performance
Mean time between failures (MTBF)
146700 h
Power
AC input voltage
85 - 264 V
DC input voltage
40 - 72 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 85%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
152 - 3048 m
Weight & dimensions
Width
444.5 mm
Depth
468.9 mm
Height
43.9 mm
Weight
9.41 kg
